WhirlMaster




Perfect for all types of whirlpools

With their compact design and light weight, WhirlMaster pumps are Aqua-Flo by Gecko’s smallest, most efficient jetted bath pumps offering the same quality, reliability, and ease of service than their spa pump counterparts at a substantially reduced cost.

Made for whirlpools

  • Single speed pump
  • 1 ½" intake and discharge
  • 100% drain
  • Optional air switch available
  • Optional electronic 30 minutes timer available
  • 15 frame size motor

WhirlMaster pumps feature:

  • NEMA 3' cord (standard US)
  • Whisper-quiet fine-tuned impeller
  • True continuous rated horsepower of ½, ¾, 1.0 & 1.5 hp
  • cULus or cURus certified

dimensions

Note that dimensions may slightly vary depending on components selection. Biggest WhirlMaster configuration illustrated above.


WhirlMaster, center discharge, single-speed, 1 ½” intake & discharge

  • Speed: 1
  • HP: 0.75, 1 or 1.5
  • Volts: 115
  • HZ: 60
  • Frame: 48
  • Cable length: 36, 48, 60, 72, 96 or 120 inches
  • Connectors: QC, QCF, AMP, in.link or Nema
  • Seals: Viton, EPDM, Universeal
  • Wet end colors: black
  • Water in: 1.5 inches
  • Water out: 1.5 inches
  • Fittings: 2 x 1.5"
  • Options: air switch and timer
  • Packaging: individual box or pallet

performance chart



Note that data results may slightly vary depending on components selection.
