Discover all Gecko pumps for spas and hot tubs with our line aqua-flo by Gecko


Circ-Master CMHP & CMCP





24-hour circulation pump



Circ-Master hp/cp pump, designed exclusively for spas, takes 24-hour filtration to a new level, delivering the highest GPM of any recirculation pump on the spa industry.

Circ-Master pumps are powerful, efficient, high density filtration and quiet.

Increase efficiency:

  • Ideal for 24/7 circ pump applications
  • Single speed
  • Flow rate up to 40 GPM
  • 1 ½ " intake and discharge
  • Wet end available in center or side discharger configuration
  • Ajustable volute with 4 different positions
  • Up to 3 drain plugs available
  • 115V or 230V
  • 48 frame

Easily customizable to fit your needs:

  • Discharge can be oriented on 4 positions
  • Fits all requirements
  • Many options for the drain plug
  • Color can be customized
  • Many power cables type available according to your spa controls
  • Many options for the compression fitting configuration
  • Compact design
  • Open drip proof
  • cULus or cURus certified

CMHP dimensions

Note that dimensions may slightly vary depending on components selection. Biggest CMHP configuration illustrated above.

CMCP dimensions

Note that dimensions may slightly vary depending on components selection. Biggest CMCP configuration illustrated above.

Note that dimensions may slightly vary depending on components selection. Biggest CMCP configuration illustrated above.


CMHP and CMCP customization variables

  • Speeds: 1
  • HP: 1/15
  • Volts: 115 or 230
  • HZ: 60
  • Frame: 48
  • Water discharge location: top, right side, bottom or left side
  • Cable length: 36, 48, 60, 72, 96 or 120 inches
  • Connectors: QC, QCF, AMP, in.link or Nema
  • Seals: Viton, EPDM, Universeal
  • Wet end colors: black, blue, green, red
  • Water in: 1.5 inches
  • Water out: 1.5 inches
  • Plugs: DP hex, DP wing, Barb 3/8, Barb 1/4
  • Fittings: 2 x 1.5" or 2 x 2" (with adaptors)
  • Packaging: individual box or pallet

performance chart



Note that data results may slightly vary depending on components selection.
